EGO TT packaging machine

Simplicity and performance at all levels, a flow-pack at the service of the product!

With a particular consideration for machine cleanliness, moisture protection and robustness, the EGO TT packaging machine is built on a solid frame.

All drive mechanisms are positioned separate from the packaging process, to prevent processing and product residues from ending up in the drive mechanisms, thus reducing cleaning operations, improving the life of the components, and ensuring the best hygienic conditions, as well as easy access for maintenance. The frame and the removable protection panels are entirely made of AISI304 stainless steel and equipped with key locks.

Feet adjustable in height, with stem and base in stainless steel, with self-draining surfaces and equipped with anti-slip and vulcanized anti-vibration rubber, FDA approved. 10” touch screen operator interface for the control of the packaging machine. Safety guards of the welding group in transparent polycarbonate with aluminium frame, openable, and equipped with safety micro switches.

The EGO TT packaging machine is an electronic machine equipped with 4 brushless and 1 asynchronous motor with BOX MOTION type sealing, ideal for packaging long-life products, through the insufflation of gas (MAP) or aromas nebulizing. It is also ideal for multi-pack packaging and for products of variable length from the same batch.

EGO TT uses only top-quality components for constant production efficiency over time and excellent final packaging results:

Electronics and motorization: OMRON / CMZ
Gearboxes: WITTENSTEIN / MOTOVARIO
Pneumatics: FESTO / CAMOZZI
Inverters: OMRON / PARKER
Operator Terminal: EXOR 10” / CMZ 10”
Sensors: SICK / PIZZATO
Belts: AMMERAAL
Support feet in stainless steel: NGI

Main technical features

Right version
AISI 304 stainless steel structure
10” color touch screen interface available in Italian and English
Built-in loader, with manual handling of the product, automatic loading on request
New sealing wheel heating system allowing to reduced energy consumption and ensure accurate temperature control.
3 pairs of welding wheels (1 cold for film pulling, 1 hot for film welding, 1 for film folding), motorized height adjustable and tiltable for better adherence of the film.
The transversal sealing system is box motion, thus making short and long packs without penalizing production. The box motion is equipped with 400 mm wide sealing jaws, with a special profile that allows to obtain airtight welding, and a greater product passage.
The sealing jaws of the machine are equipped with resistances controlled by precision thermoregulators a knife. The infeed and outfeed conveyors of the sealing unit are equipped with food-safe, sealed belts.
Motorized expansion reel holder shaft, with fine adjustment of reel centering and compensation brake. Reel width 800mm
Photocell for centered printing
Motorized or pneumatic pad for removing excess air from packages
Protections guards in lexan, with natural anodized aluminum frame, openable and equipped with safety sensors
Standard speed 60pcs/minute (based on the product to be packaged)
Power supply: 400 + Neutral – 50Hz
Consumption: 14 Amp – 6 Bar (continuously)

Main optionals

Left version
Automatic loading conveyor
Preheating system
Eurohole
4 sets of welding groups
No product – No bag
Gas insufflation
Micrometric dosing of liquids (alcohol anti-mould)
Residual gas analyzer
Double shaft with automatic reel change
Automatic rejection of non-compliant products
Machine’s frame on wheels
Printer / Labeler
Remote assistance device. The router allows remote control of the parameters allowing to identify any operating anomalies and to intervene.
